MW Mean Well SDR-480-48 48V 10A DIN Rail Power Supplies
Product details
| Management number | 212190703 | Release Date | 2026/04/06 | List Price | US$63.04 | Model Number | 212190703 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
FeaturesHigh efficiency up to 94%Universal AC input / Full range (SDR-75/120/240/480) AC input 180~264VAC only (SDR-960)Built-in active PFC function (SDR-120/240/480/960)Protections: Short circuit / Overload / Over voltage / Over temperatureCooling by free air convectionCan be installed on DIN rail TS-35 / 7.5 or 15UL508(industrial control equipment) approvedEN61000-6-2(EN50082-2) industrial immunity levelBuilt-in DC OK relay contact (except for SDR-75)150% peak load capability (SDR-75/120/240/480)130% peak load capability (SDR-960)Current sharing up to 3840W (7+1) for SDR-480PCurrent sharing up to 3840W (3+1) for SDR-960Comply with GL (SDR-120/240/480)Comply with SEMI F47 (SDR-75/120/240/480)3 years warranty
- High efficiency up to 94%
- Built-in active PFC function (SDR-120/240/480/960)
- Can be installed on DIN rail TS-35 / 7.5 or 15
- Built-in DC OK relay contact
- 3 years warranty
| Brand | MEAN WELL |
|---|---|
| Wattage | 3840 watts |
| Form Factor | DIN Rail |
| Item Weight | 3.52 ounces |
| Manufacturer | MEAN WELL |
| Model Number | SDR-480-48 |
| Cooling Method | Air |
| Current Rating | 10 Amps |
| Output Wattage | 3840 Watts |
| Item Dimensions | 3.39 x 4.96 x 5.08 inches |
| Mfr Part Number | SDR-480-48 |
| Compatible Devices | Personal Computer |
| Maximum Input Voltage | 264 Volts (AC) |
| Minimum Input Voltage | 180 Volts (AC) |
| System Bus Connector Type | ATX |
| Connector Type Used on Cable | ATX |
| EU Spare Part Availability Duration | 3 Years |
