Mobile Hydraulic Oil Cooler, 0-120 GPM, 60HP, with Dual 12V Fans with or Without Bypass (No Bypass)
Product details
| Management number | 212694980 | Release Date | 2026/04/06 | List Price | US$682.44 | Model Number | 212694980 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Heavy Duty Aluminum Bar and Plate Hydraulic Oil Cooler w/ 12V Fan & Shroud DC-60. Assembly needs to be installed on the Low Pressure side of hydraulic circuit Applications: Fits Mobile and Industrial Hydraulics Our Part Number: 24641 – No Bypass 26313 – 2 Bar (29 psi) Bypass 26314 – 5 Bar (73 psi) Bypass 26315 – 8 Bar (116 psi) Bypass Core (Finned area) Dimensions: 39.6” x 19.5” x 2.56” Inlet: -20 SAE O-Ring Seal (1-5/8-12 UN-2B) Outlet: -20 SAE O-Ring Seal (1-5/8-12 UN-2B) Overall Dimensions: 46.7” x 22” x 8.2” Max Working Temp: 250°F Max Working Pressure: 360 psi Fan Data: 12 Volt DC Electric Motor 22AMP Current Draw MetriPack 280 Connector (Male and Female connectors included) Flow Range: 0-120 GPM
- Heavy Duty Construction: Features aluminum bar and plate construction for superior durability and heat dissipation in demanding hydraulic applications
- Multiple Bypass Options: Available in 4 variations of bypass ratings to suit different system requirements and pressure specifications
- Bypass Rating Configurations: Choose from No Bypass, 2 Bar Bypass (29 psi), 5 Bar Bypass (73 psi), or 9 Bar Bypass (116 psi) options
- Standard Connections and Power: Equipped with #20 SAE O-ring connections for secure fitting and dual 12V fans for efficient cooling performance
- High Flow Capacity: Handles flow rates from 0 to 120 GPM with 60HP cooling capacity, suitable for mobile and industrial hydraulic systems
| Voltage | 12 Volts |
|---|---|
| Brand Name | American Cooling Solutions |
| Unit Count | 1.0 Count |
| Item Weight | 50 Pounds |
| Manufacturer | American Cooling Solutions |
| Cooling Method | forced air |
| Air Flow Capacity | 120 Gallons Per Minute |
| Compatible Devices | Heavy Machinery, Industrial Equipment, Vehicles |
| Power Connector Type | 4-Pin |
| Maximum Rotational Speed | 120 RPM |
| Item Dimensions L x W x H | 39.6"L x 19.5"W x 2.56"H |
